Tyre Size (Inch) | Pneumatique Size (Inches) | Tyre Size (mm) | Rim Size | Tread | Tyre Dimensions(mm) | Load Capacity (10km/hr) Kg | ||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|
JIS-491 | JIS-492 | Outer Dia. | Section Width | |||||||||
31x10-16 | 10x16.5 | 6.00-16 | • | 785 | 255 | 3660 | ||||||
31x10-18 | 7.00-18 | • | 785 | 255 | 3660 | |||||||
31x10-20 | 10x16.5 | 7.50-20 | • | • | 785 | 255 | 3660 | |||||
31x9-16 | 10x16.5 | 6.00-16 | • | • | 785 | 230 | 2550 | |||||
33x9-16 | 10x16.5 | 6.00-16 | 840 | 230 | 3880 | |||||||
33x12-20 | 12x16.5 | 7.50-20 | • | • | 840 | 290 | 4720 | |||||
35x10-16 | 14x17.5 | 6.00-16 | 890 | 255 | 3000 | |||||||
36x12-16 | 14x17.5 | 6.00-16 | 915 | 305 | 4000 | |||||||
36x12-20 | 14x17.5 | 7.50-20 | 920 | 305 | 4585 | |||||||
36x14-20 | 14x17.5 | 7.50-20 | 920 | 330 | 5605 | |||||||
• Available |
Solid Skid Steer - Flotation Demountable Range
Solid Skid Steer - Flotation Mold-On Range
Tyre Size (Inch) | Pneumatique Size (Inches) | Tyre Size (mm) | Rim Size | Tread | Tyre Dimensions(mm) | Load Capacity (10km/hr) Kg | ||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|
JIS-491 | JIS-492 | Outer Dia. | Section Width | |||||||||
31x4x9 | 10x16.5 | 785 | 230 | 2645 | ||||||||
31x5x9 | 10x16.5 | 785 | 230 | 2680 | ||||||||
31x6x10 | 10x16.5 | 785 | 255 | 2990 | ||||||||
32x5x10 | 12x16.5 | 815 | 255 | 3805 | ||||||||
33x6x10 | 12x16.5 | • | • | 840 | 255 | 3330 | ||||||
33x6x11 | 12x16.5 | • | • | 840 | 280 | 3590 | ||||||
35x7x10 | 14x17.5 | 890 | 255 | 3000 | ||||||||
36x7x11 | 14x17.5 | 915 | 280 | 3875 | ||||||||
40x9x13 | 15x19.5 |
