Solid Skid Steer Grades - The Full Spectrum
|
|
TYRE SIZE (METRIC) |
RIM |
TREAD |
Tyre Dimensions in mm |
Load capacity on fork lifts, kg at 25kmph |
| OUTER DIA. |
SIDEWALL WIDTH |
TREAD WIDTH |
LOAD WHEEL |
STEER WHEEL |
| 3.00 - 4 |
|
2.10 |
JIS-481 |
245 |
85 |
75 |
260 |
195 |
| 3.50 - 4 |
|
2.10 |
JIS-481 |
250 |
89 |
83 |
260 |
195 |
| 4.00 - 4 |
|
2.50 |
JIS-482 |
300 |
92 |
84 |
535 |
412 |
|
|
|
|
|
|
|
|
|
| 3.50 - 5 |
|
3.00 |
JIS-481 |
300 |
100 |
90 |
900 |
690 |
|
140/55-6 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| 4.00 - 8 |
|
2.75, 3.00 |
JIS-482, JIS-481 |
402 |
103 |
86 |
950 |
730 |
| 4.00 - 8 |
|
3.75 |
JIS-481 |
405 |
119 |
86 |
950 |
730 |
| 12x3 1/2 - 8 |
|
3.00 |
JIS-483 |
308 |
98 |
87 |
850 |
650 |
|
100/80-8 |
2.50 |
JIS-483 |
360 |
105 |
90 |
1,000 |
770 |
| 15X4 1/2 - 8 |
125/75-8 |
3.00, 3.25 |
JIS-482 |
368 |
105 |
90 |
1,040 |
800 |
| 15X4 1/2 - 8 |
125/75-8 |
3.00, 3.25 |
JIS-483 |
378 |
110 |
100 |
1,040 |
800 |
| 5.00 - 8 |
|
3.00 |
JIS-482 |
450 |
120 |
110 |
1,415 |
1,090 |
| 5.00 - 8 |
|
3.75 |
JIS-481 |
450 |
125 |
110 |
1,415 |
1,090 |
| 16X6 - 8 |
150/75-8 |
4.33 |
JIS-482 |
406 |
140 |
125 |
1,270 |
975 |
| 17X7 - 8 |
|
4.33 |
JIS-483 |
430 |
150 |
134 |
2,000 |
1,540 |
| 18X7 - 8 |
180/70-8 |
4.33 |
JIS-482 |
450 |
157 |
142 |
2,145 |
1,650 |
|
|
|
|
|
|
|
|
|
|
140/55 - 9 |
4.00 |
JIS-482 |
376 |
125 |
110 |
1,170 |
900 |
| 6.00 - 9 |
|
4.00 |
JIS-482 |
520 |
138 |
120 |
1,885 |
1,450 |
| 21X8 - 9 |
200/75-9 |
6.00 |
JIS-482 |
517 |
188 |
157 |
2,755 |
2,120 |
|
|
|
|
|
|
|
|
|
|
200/50 - 10 |
6.50 |
JIS-482 |
454 |
190 |
160 |
2,470 |
1,900 |
| 6.50 - 10 |
|
5.00, 5.50 |
JIS-482 |
566 |
160 |
140 |
2,340 |
1,800 |
| 7.50 - 10 |
|
5.00, 5.50 |
JIS-482 |
630 |
170 |
150 |
3,070 |
2,360 |
| 23X9 - 10 |
225/75-10 |
6.50 |
JIS-482 |
580 |
194 |
178 |
3,160 |
2,430 |
|
|
|
|
|
|
|
|
|
| 7.00 - 12 |
|
5.00 |
JIS-482 |
646 |
172 |
150 |
2,920 |
2,240 |
| 23X10 - 12 |
|
8.00 |
JIS-482 |
580 |
232 |
200 |
3,770 |
2,900 |
| 27X10 - 12 |
250/75-12 |
8.00 |
JIS-482 |
672 |
240 |
200 |
3,900 |
3,000 |
|
|
|
|
|
|
|
|
|
| 23X5 - 13 |
|
3.75 |
JIS-482 |
605 |
122 |
102 |
1,495 |
1,150 |
|
|
|
|
|
|
|
|
|
| 7.00 - 15 |
|
5.50 |
JIS-482 |
705 |
180 |
158 |
3,545 |
2,725 |
| 7.50 - 15 |
|
5.50, 6.00, 6.5 |
JIS-482 |
|
736 |
193 |
168 |
3,900 |
| 3,000 |
|
|
|
|
|
|
|
|
| 8.15-15 (28X9-15) |
225/75-15 |
7.00 |
JIS-482 |
678 |
221 |
190 |
3,445 |
2,650 |
| 8.25 - 15 |
|
6.50 |
JIS-482 |
808 |
192 |
173 |
4,750 |
3,650 |
| 2.50 - 15 |
250/70-15 |
7.00, 7.50 |
JIS-482 |
706 |
220 |
190 |
4,745 |
3,650 |
| 3.00 - 15 |
315/70-15 |
8.00 |
JIS-482 |
806 |
242 |
223 |
5,850 |
4,500 |
| 28X12.5-15 |
345/45-15 |
9.75 |
JIS-482 |
705 |
275 |
255 |
5,525 |
4,250 |
|
355/65-15 |
9.75 |
JIS-482 |
810 |
285 |
265 |
7,000 |
5,450 |
|
400/60-15 |
11.00 |
JIS-482 |
810 |
318 |
298 |
8,970 |
6,900 |
|
|
|
|
|
|
|
|
|
| 7.50 - 16 |
|
5.50, 6.00, 6.5 |
JIS-482 |
|
736 |
193 |
168 |
3,900 |
| 3,000 |
|
|
|
|
|
|
|
|
| 8.25 - 16 |
|
5.50, 6.00 |
JIS-482 |
808 |
192 |
173 |
4,750 |
3,650 |
|
|
|
|
|
|
|
|
|
| 7.50 - 20 |
|
6.00 |
JIS-482 |
870 |
200 |
175 |
3,900 |
3,250 |
| 8.25 - 20 |
|
6.50 |
JIS-482 |
915 |
200 |
180 |
4,380 |
3,650 |
|
355/50 - 20 |
10.00 |
JIS-483 |
810 |
285 |
265 |
8,970 |
6,900 |
| 9.00 - 20 |
|
6.50, 7.00 |
JIS-482 |
972 |
226 |
191 |
5,400 |
4,500 |
| 10.00 - 20 |
|
7.50, 8.00, 8.5 |
JIS-482 |
|
1,004 |
250 |
203 |
6,000 |
| 5,000 |
|
|
|
|
|
|
|
|
| 10.00 - 20 |
|
7.50, 8.00, 8.5 |
JIS-483 |
SM |
1,050 |
265 |
235 |
6,000 |
| 5,000 |
|
|
|
|
|
|
|
|
| 10.00 - 20 |
|
8.00 |
JIS-482 |
SCR |
1,050 |
265 |
235 |
6,000 |
| 11.00 - 20 |
|
7.50, 8.00, 8.5 |
JIS-483 |
SM |
1,050 |
265 |
235 |
6,000 |
| 5,000 |
|
|
|
|
|
|
|
|
| 12.00 - 20 |
|
8.00, 8.50 |
JIS-482 |
1,080 |
255 |
232 |
7,560 |
6,300 |
| 12.00 - 20 |
|
8.00, 8.50 |
JIS-483 |
1,140 |
295 |
250 |
7,560 |
6,300 |
| 13.00 - 20 |
|
8.00, 8.50 |
JIS-483 |
1,140 |
295 |
250 |
7,560 |
6,300 |
|
|
|
|
|
|
|
|
|
| 12.00 - 24 |
|
8.50, 10.00 |
JIS-482 |
1,165 |
265 |
230 |
8,040 |
6,700 |
| 14.00 - 24 |
|
10.00 |
JIS-482 |
1,275 |
308 |
270 |
11,100 |
9,250 |
| 14.00 - 25 |
|
10.00 |
JIS-482 |
1,275 |
308 |
270 |
11,100 |
9,250 |
